TOOLKITRC M7 200W 10A DC BALANCE CHARGER
TOOLKITRC M7 200W 10A DC BALANCE CHARGER

TOOLKITRC M7 200W 10A DC BALANCE CHARGER

Vendor
ToolkitRC
Regular price
1,750.00 ฿
Sale price
1,750.00 ฿
Unit price
per
Shipping calculated at checkout.

M7 SPECS:

  • Product size: 73*51*27 mm
  • Product weight: 90g
  • Pack size: 84*79*39 mm
  • Pack weight: 150g
  • LCD: IPS  2.0inch LCD 320*240 Pixel
  • Input voltage: 7.0-28.0V  @MAX 12A
  • Type of battery: Lipo  LiHV  LiFe Lion@1-6 | NiMh @1-16S   Pb @1-10S
  • Balance current: 400mA @2-6S
  • Charger power: 200W @MAX 10A
  • Discharge power: 200W  @MAX 10A Recycle mode | 10W@3A Normal mode
  • USB: 2.1A @5.0V or Upgrade

INPUT:

  • PWM: 880-2200us @20-400Hz
  • PPM: 880-2200us*8CH @20-50Hz
  • SBUS: 880-2200us*16CH @20-100Hz
  • Voltage: 1.0-5.0V @1-6S
  • Internal resistance: 1-99mR @1-6S
  • ESC: 200W@10A | PWM Output

OUTPUT:

  • PWM: 500-2500us @20-1000Hz
  • PPM: 880-2200us*8CH @20-50Hz
  • SBUS: 880-2200us*16CH @20-100Hz
  • Power supply: 1.0-28.0V  @1.0-10A  mode:CC+CV
  • OverCurrent Cutoff time: <5ms

PACKAGING INCLUDED:

  • 1X ToolkitRC M7 Charger
